Cap Kit - WIN! And now..My Turbo is 95%!

Okay, so I got some GREAT help on the KLOV.com, coinopspace.com, and RGVAC groups. Turns out, my issue was I had the "Screen" knob on the flyback transformer cranked way up. And, everything else was out of whack too.

So, I tried the "screen", and failed. But, that was because I wasn't using a mirror, and was just running back and forth from back to front.

I found a cheap full length mirror, propped it up, and started working on it. By that point, I'd already started jumping it over to my Lock n Chase.

I have some old speaker wire from a cheap surround sound system that went tits up, so I just jammed that in the appropriate molex connectors, and found that I could mostly get it tuned it.

Damn, skippy, I was happy. So, I quickly hooked the Turbo back up, and boo yah!

In that picture, you can see how the left side of the screen had this weird "fold" in it. I was so damn happy, I didn't care, and played 20 games.

It was like 25 years ago, back in the day, at the Minot, ND "Bump N Tilt" free play arcade. The "drifting" game play using the pedal, and the "spin stop" motion of the wheel, and the way I'd spin in my initials "FUZ" on it.

You just can't beat that feeling.

You also can't beat the "my left leg has lost all feeling" feeling that Sega Turbo gives. LOL. Damn, I'd forgotten all about that! Since actually coordinating pedal movement with steering is key in Turbo, you really have to just fix on your left leg. And, after a while, it's painful.

I'm gonna have to get me a stool now. (I will anyway to help the kiddos play.)

Anyway, I fixed the fold by adjusting the vertical size... but I still have an issue. Aliens are eating the cars...

(The slight white line across the bottom of the screen is my hint the horizontal size is too big.)

Here's a video of the alien attack (before I'd fixed the vertical size issue...)



BTW, you'd think it's a "horizontal" size issue. But as James on RGVAC pointed out to me, every monitor is 4:3 horizontal. Even if it's mounted vertically. "Horizontal" always the long width.

Cap kit - FAIL!

2 weeks ago, I got up in there, and discovered 2 screws and 2 little nuts I could get to on the board. On a Turbo, there's 2 nuts right in front, the 2 screws are on tabs, about 8 inches back. (The board is a square, and they're right on the ends.) So, finally, I had my "way in". That was probably my biggest mental hurdle

4 days ago, I finally had time to put my capacitors on a styrofoam block. (awesome idea from that video.) The kids helped. It was kinda fun. I'd find a cap, start it, and they'd push it the rest of the way in.

Sunday, I got my light-on-a-stick, and assembled my tools.

Tuesday, finally, I had my opportunity... Everyone was downstairs.... the kids were playing nicely in the castle, the wife was on the couch reading a book, and so I snuck off.

Unhooking the cables was a snap. I had to use a stubby phillips head to get the 2 screws in the back out. And, I had to sit on a stool, and turn my head halfway up the game just to see the lower screw in the back. Almost stripped that one's head, but, I finally got them. The nuts in front were simple.

One note that wasn't in the guides was that, on the neckboard, there is a little "V" of plastic out the back that is the actual connector. I kept wiggling the board itself, and things weren't moving. Then, I tried the "V", and it worked great.

Here's my "workstation", LOL. That's newspapers on a vintage 70's TV tray, LOL.

Damn, some of the caps on that board are _really_ wedged in tight. Can you say, disgusting mess?


10 paper towels and 4 ounces of LA's Totally Awesome later...
Look at that. Purdy. Everything on that board, once cleaned a bit, looks like "the day it was installed", save for some surface rust on the metal surfaces. Mmmm, nachos!
But, I got in there and got the job done. (Nuts in place, screws not yet...)

But.... ARGGGGHHHH!!!! The Turbo STILL plays blind. Before the cap kit, these lines were just part of a bigger annoyance of a faded screen that collapsed into a vertical line straight down the center.



Can anyone help???
